Installing the optical fibre cable to the decorative strip

• Clip in the fibre-optic cable (1) into the latch mechanisms of the decorative strip (2).
• While doing so, make sure to position retaining lug (3) of the optical fibre cable correctly in the decorative trim (2).

  Courtesy of BMW OF NORTH AMERICA, INC.

Follow-up Work

• Install the front door trim panel LED MODULES .
• Install the finisher on the door TRIM PANEL .
• Install front door TRIM PANEL .
• Install the mirror triangle COVER .
• Attach the door handle COVER .
