Install the pressure sensor on the left charge air cooler

• Check the sealing ring (1) on the pressure sensor for damage and replace the sealing ring if necessary.

  Courtesy of BMW OF NORTH AMERICA, INC.

• Position pressure sensor (1) on the charge air cooler.
• Tighten down screws (2).
  TIGHTENING TORQUES SPECIFICATION



  Pressure sensor to charge air cooler
  Screw TS6x12	Tightening torque	3.2 Nm

  Courtesy of BMW OF NORTH AMERICA, INC.

• Connect connectors (1) and lock.

Courtesy of BMW OF NORTH AMERICA, INC.

Follow-up work

• Refer to INSTALLING THE RIGHT INTAKE FILTER HOUSING WITH THE RIGHT FRONT-END STRUT .
• Refer to INSTALLING LEFT INTAKE FILTER HOUSING WITH LEFT FRONT-END STRUT .
• Refer to INSTALLING THE COVER ON THE LEFT AND RIGHT IN THE ENGINE COMPARTMENT AT THE TOP
