Supplying The New Parts Required

NOTE: TECHNICAL INFORMATION

Observe the procedure for repair stage 2.
For additional information see: REPAIR TECHNIQUES, REPAIR STAGE 2 - (530I 2017-2022, 530I XDRIVE 2017-2022, 530E PHEV 2018-2022, 530E XDRIVE PHEV 2018-2022, 540I 2017-2022, 540I XDRIVE 2017-2022, M550I XDRIVE 2018-2022) .
For information about stripping and rebuilding operations, refer to the surrounding text in the AIR. See the FRU number.

Further information is available .

Prepare the following new parts (see Electronic Parts Catalog [EPC]):
Rear wall (1)

Reinforcement plate, door sill

Reinforcement plate, C-pillar

Plastic nut

NOTE: TECHNICAL INFORMATION
For additional information see: OVERVIEW OF CONSUMABLES (ELECTRONIC PARTS CATALOG) - (530I 2017-2022, 530I XDRIVE 2017-2022, 530E PHEV 2018-2022, 530E XDRIVE PHEV 2018-2022, 540I 2017-2022, 540I XDRIVE 2017-2022, M550I XDRIVE 2018-2022) .

G14194924

Courtesy of BMW OF NORTH AMERICA, INC.

Supply the following consumables:

Material	Quantity
Adhesive K5 (195 ml)	1
Adhesive K5 (50 ml)	1
Blind rivet N3	20
Punch rivet N4	35
Punch rivet N5	5
EMC screw	4
Cleaning agent R1	1
Cleaning agent R2	1
Cavity protection wax remover
Sealing compound D1
