Detach the top left and right wishbone from the swivel bearing
NOTE:
Perform the steps on the right and left side.
Detach the upper wishbone from the swivel bearing
- Release nut (1).
- Pull out screw (2).
- Release upper wishbone (3) from the swivel bearing (4).
(F) = driving direction
Courtesy of BMW OF NORTH AMERICA, INC.
|
