Table for classifying guide bearing shell 4 (B58TU1) (540i, 2017-2020, 540i, 2021-2022, 540i xDrive, 2021-2022)

G14229137Courtesy of BMW OF NORTH AMERICA, INC.

Uppercase letter on the crankcase

Lowercase letter on the crankshaft

  A B C D E H J K L M N P
a →  1 1 1 1 1 1 1 1 1 1 1 1
1 1 1 1 1 1 1 1 1 1 1 1
b →  1 1 1 1 1 1 1 1 1 1 1 1
1 1 1 1 1 1 1 1 1 1 1 2
c →  1 1 1 1 1 1 1 1 1 1 1 1
1 1 1 1 1 1 1 1 1 2 2 2
d →  1 1 1 1 1 1 1 1 1 1 1 1
1 1 1 1 1 1 1 1 2 2 2 2
e →  1 1 1 1 1 1 1 1 1 1 1 1
1 1 1 1 1 1 1 2 2 2 2 2
f →  1 1 1 1 1 1 1 1 1 1 1 1
1 1 1 1 1 2 2 2 2 2 2 2
h →  1 1 1 1 1 1 1 1 1 1 1 1
1 1 1 1 2 2 2 2 2 2 2 2
j →  1 1 1 1 1 1 1 1 1 1 1 2
1 1 1 2 2 2 2 2 2 2 2 2
k →  1 1 1 1 1 1 1 1 1 2 2 2
1 1 2 2 2 2 2 2 2 2 2 2
m →  1 1 1 1 1 1 1 1 2 2 2 2
2 2 2 2 2 2 2 2 2 2 2 2
n →  1 1 1 1 1 1 1 2 2 2 2 2
2 2 2 2 2 2 2 2 2 2 2 2
p →  1 1 1 1 1 2 2 2 2 2 2 2
2 2 2 2 2 2 2 2 2 2 2 2
r →  1 1 1 1 2 2 2 2 2 2 2 2
2 2 2 2 2 2 2 2 2 2 2 2
t →  1 1 1 2 2 2 2 2 2 2 2 3
2 2 2 2 2 2 2 2 2 2 2 2
u →  1 1 2 2 2 2 2 2 2 3 3 3
2 2 2 2 2 2 2 2 2 2 2 2
v →  2 2 2 2 2 2 2 2 3 3 3 3
2 2 2 2 2 2 2 2 2 2 2 2
w →  2 2 2 2 2 2 2 3 3 3 3 3
2 2 2 2 2 2 2 2 2 2 2 2
x →  2 2 2 2 2 3 3 3 3 3 3 3
2 2 2 2 2 2 2 2 2 2 2 2
y →  2 2 2 2 3 3 3 3 3 3 3 3
2 2 2 2 2 2 2 2 2 2 2 2
z →  2 2 2 3 3 3 3 3 3 3 3 3
2 2 2 2 2 2 2 2 2 2 2 3
