Component Location Overview - Vehicle Interior Trim Panels, Sedan

Fig 1: Vehicle Interior Trim Panels, Sedan Overview

1. D-Pillar Trim Panel
   • Overview. Refer to OVERVIEW - D-PILLAR TRIM PANEL .
2. C-Pillar Trim Panel
   • Overview. Refer to OVERVIEW - C-PILLAR TRIM PANEL .
3. Rear Sill Panel
   • Overview. Refer to OVERVIEW - SILL PANEL .
4. B-Pillar Lower Trim Panel
   • Overview. Refer to OVERVIEW - B-PILLAR TRIM PANEL .
5. B-Pillar Upper Trim Panel
   • Overview. Refer to OVERVIEW - B-PILLAR TRIM PANEL .
6. Front Sill Panel
   • Overview. Refer to OVERVIEW - SILL PANEL .
7. Footrest
   • Removing and installing. Refer to FOOTREST, REMOVING AND INSTALLING .
8. A-Pillar Gap Cover
   • Removing and installing. Refer to A-PILLAR TRIM PANEL, REMOVING AND INSTALLING .
9. A-Pillar Trim Panel
   • Overview. Refer to OVERVIEW - A-PILLAR TRIM PANEL .
10. Carpet
    • Overview. Refer to OVERVIEW - FOOTREST AND CARPET .
11. Rear Shelf
    • Overview. Refer to OVERVIEW - REAR SHELF .
