44 Collapsible Spare Wheel Does Not Inflate Fully Using The Compressor From The Vehicle Tool Kit (GROUP 44, NO. 23-02)
Reference number: GROUP 44, NO. 23-02
Supersedes refnos: 2065160/1, 2065160/2, GROUP 44, NO. 21-84
44 COLLAPSIBLE SPARE WHEEL DOES NOT INFLATE FULLY USING THE COMPRESSOR FROM THE VEHICLE TOOL KIT
TECHNICAL SERVICE BULLETIN
| AUDI: | 2020-2025 All Audi Vehicles |
| GROUP: | 44 - Wheels - Tires, Wheel Alignments |
SERVICE INFORMATION
44 23 02 2065160/2 August 4, 2023. Supersedes Technical Service Bulletin Group 44 number 21-84 dated November 19, 2021, for reasons listed below.
| Model(s) | Year | VIN Range | Vehicle-Specific Equipment |
|---|---|---|---|
| All Audi Vehicles | 2020 - 2025 | All | Not Applicable |
CONDITION
| Revision | Date | Purpose |
|---|---|---|
| 2 | - | Revised header (Added Model Years) |
| 1 | 11/19/2022 | Initial publication |
Customer states:
- The temporary/collapsible spare wheel does not inflate fully when it is filled using the compressor from the breakdown set. The pressure specified on the collapsible spare wheel is not reached using the compressor.
TECHNICAL BACKGROUND
The collapsible spare wheel is in suitable condition to use on the vehicle when the tire tread is aligned horizontally with the hub. When this is the case, the side wall of the collapsible spare wheel may not be aligned symmetrically with the rim, giving the impression that the tire has not inflated fully. The compressor reaches a pressure-3>.5 bar after running for a certain period; this is sufficient for using the tire (Figures 1 - 2).
© 2023 Audi of America.
All rights reserved. Information contained in this document is based on the latest information available at the time of printing and is subject to the copyright and other intellectual property rights of Audi of America, Inc., its affiliated companies and its licensors. All rights are reserved to make changes at any time without notice. No part of this document may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, nor may these materials be modified or reposted to other sites, without the prior expressed written permission of the publisher.
PRODUCTION SOLUTION
Not applicable.
SERVICE
Not Applicable.
WARRANTY
This TSB is informational only and not applicable to any Audi Warranty.
ADDITIONAL INFORMATION
All part and service references provided in this TSB (2065160) are subject to change and/or removal. Always check with your Parts Department and/or ETKA for the latest information and parts bulletins. Please check the Repair Manual for fasteners, bolts, nuts, and screws that require replacement during the repair.
