Remove ventilation temperature sensor
Preliminary works
- DEACTIVATE the 48 v electrical system.
- Disconnect all battery EARTH LEADS .
- Remove the rear passenger compartment air conditioning CONTROL PANEL (integrated automatic heating/air conditioning system with 4-zone control).
- Remove the rear VENTILATION GRILLE .
- Remove the rear VENTILATION GRILLE (air conditioning with 4-zone control).
- Remove the rear center console TRIM .
- Remove the center armrest STORAGE COMPARTMENT .
- Remove the center ARMREST .
- Remove the front storage compartment TRIM .
- Remove the center console TRIM .
- Remove CUPHOLDER .
- Remove the pedal mechanism TRIM PANEL .
- Remove the right footwell TRIM .
- Remove the CENTER CONSOLE .
- Remove the right instrument panel SIDE PANEL .
- Remove the right instrument panel FINISHER .
- Remove the radio operating unit and the air conditioning CONTROL PANEL .
- Remove HEAD UNIT HIGH (HU-H).
- Remove the instrument panel speaker TRIM .
- Remove the instrument panel MID-RANGE SPEAKER .
- Remove both inner front door sill COVER STRIPS .
- Remove the left a-pillar footwell side TRIM PANEL .
- Remove the right-hand a-pillar footwell side TRIM PANEL .
- Remove the left and right a-pillar TRIM PANEL .
- Remove the left instrument panel SIDE PANEL .
- Remove the light OPERATING UNIT .
- Remove the left instrument panel FINISHER .
- Remove CENTRAL INFORMATION DISPLAY (CID).
- Remove the left fold-down COMPARTMENT .
- Remove the steering wheel/sports steering wheel AIRBAG UNIT .
- Remove the M sports steering wheel AIRBAG UNIT .
- Remove the STEERING WHEEL .
- Remove steering upper section column SHROUD .
- Remove steering lower section column SHROUD .
- Remove the steering column SWITCH CLUSTER (SZL).
- Remove the INSTRUMENT CLUSTER (KOMBI).
- Remove instrument panel TRIM .
